Especificaciones

Procesamiento

 M-5000

M-5000C

Canales de Mezcla

Up to 128 CH (combination of INPUT CHANNEL, MAIN, SUBGROUP, AUX, MIX-MINUS, MATRIX, MONITOR, COMM, OSC, HEADPHONES)

Entradas

Max 300 ports (96 kHz), Max 460 ports (48 kHz / 44.1 kHz)

• CONSOLE: 16  .AES/EBU: 4 .REAC: 40 x 2

• EXPANSION SLOT: 80 x 2 (96 kHz), 160 x 2 (48 kHz / 44.1 kHz)

• USB AUDIO: 16 .DOCK: 2 .USB RECORDER: 2

• FX 1L-8R: 16 .TALKBACK: 2 .OSC: 2

Salidas

• AES/EBU: 4 • REAC: 40 x 2 • USB AUDIO: 16

• EXPANSION SLOT: 80 x 2 (96 kHz), 160 x 2 (48 kHz / 44.1 kHz)

• USB AUDIO: 16 • DOCK: 2 • USB RECORDER: 2 • FX 1L-8R: 16

Max 296 ports (96 kHz), Max 456 ports (48 kHz / 44.1 kHz)

• CONSOLE: 16

Max 288 ports (96 kHz), Max 448 ports (48 kHz / 44.1 kHz)

• CONSOLE: 8

Procesamiento Interno

72 bits (fixed point, bus summing)

Procesamiento de Señal

AD/DA Conversion: 24 bit

Sampling Rate: 96 kHz, 48 kHz, 44.1 kHz

Latencia de Consola

Network Latency: 1.6 ms (typ.)

Console Latency: 1.1 ms (typ.)

* Network Latency: Total system latency of audio signal from S-2416 inputs to outputs via M-5000's REAC ports (A or B).

* Console Latency: Total system latency of audio signal from console inputs to console outputs.

* Sampling rate: 96 kHz

* Effect: No insert effects

* When a REAC Splitter S-4000D or a switching hub is used in-line with REAC cables, the network latency will increase by the amount of processing delay introduced by the splitting device itself. The actual delay is dependent upon the specifications of the splitting device, though the maximum delay amount for a single splitting device should be about 200 microseconds.

Conectores

 M-5000

M-5000C

Conectores

INPUT jacks (1 - 16): XLR-3-31 type (balanced, phantom power)

TALKBACK MIC 2 jack: XLR-3-31 type (balanced, phantom power)

AES/EBU IN jacks (1/2, 3/4): XLR-3-31 type

PHONES 1 jack: Stereo 1/4 inch phone type

PHONES 2 jack: Stereo miniature phone type

AES/EBU OUT jacks (1/2, 3/4): XLR-3-32 type

REAC ports (A, B, SPLIT/BACKUP): RJ-45 EtherCon type, REAC SPLIT/BACKUP port supports REAC EMBEDDED POWER.

WORD CLOCK connector (IN, OUT): BNC type

RS-232C connector: DB-9 type

MIDI connector (OUT/THRU, IN)

USB port (MEMORY): USB type A

USB WLAN ADAPTOR port: USB type A

USB COMPUTER port: USB type B

LAN port: RJ45 type

DOCK CABLE port: 10-pin mini DIN type

GP I/O port: DB-25 type

FOOT SWITCH jacks (1, 2): 1/4-inch TRS phone type V/500 mA

EXT.POWER DC IN jack: XLR-4-32 type

* XLR type: 1 GND, 2 HOT, 3 COLD

* Phantom power: DC +48 V (unloaded maximum), 14 mA (maximum load) (All XLR type inputs)

OUTPUT jacks (1 - 16) : XLR-3-32type (balanced)

LAMP jacks: XLR-4-31 type × 2, LAMP power DC+12 V/500 mA

OUTPUT jacks (1 - 8) : XLR-3-32type (balanced)

LAMP jacks: XLR-4-31 type × 1, LAMP power DC+12 V/500 mA

Caracteristicas de las Entradas/Salidas

 M-5000

M-5000C

Respuesta de Frecuencia (típo * 1 * 2)

PHONES jacks (1, 2): -2 dB / +0 dB (32 ohms load, 150 mW, 20 Hz to 40 kHz)

OUTPUT jacks (1 - 16): -2 dB / +0 dB (20k ohms load, +4 dBu, 20 Hz to 40 kHz)

OUTPUT jacks (1 - 8): -2 dB / +0 dB (20k ohms load, +4 dBu, 20 Hz to 40 kHz)

Distorsión Armónica Total + Ruido (típo * 1 * 2)

PHONES jacks (1, 2): (1, 2): 0.01 % (32 ohms load, 150 mW)

OUTPUT jacks (1 - 16):  0.007 % (+4 dBu)

OUTPUT jacks (1 - 8):  0.007 % (+4 dBu)

Rango Dinámico
(IHF-A, tipo * 1 * 2)

OUTPUT jacks (1 - 16): 102 dB

OUTPUT jacks (1 - 8): 102 dB

Diafonia @ 1 kHz
(IHF-A, tipo * 1 * 2)

INPUT jacks (1 - 16): -100 dB

OUTPUT jacks (1 - 16):  -109 dB

OUTPUT jacks (1 - 8): -109 dB

Impedancia de Entrada

INPUT jacks (1 - 16): 7 k ohms

TALKBACK MIC 2 jack: 4 k ohms (Phantom: ON)

Nivel Nominal de Entrada (Variable, típico)

INPUT jacks (1 - 16): -65 to -10 dBu (Pad: OFF), -45 to +10 dBu (Pad: ON)

TALKBACK MIC 2 jack: -65 to -10 dBu

Máximo Nivel de Entrada Non Clip (1kHz, típico)

INPUT jacks (1 - 16): +8 dBu (Pad: OFF), +28 dBu (Pad: ON)

TALKBACK MIC 2 jack: +8 dBu

Impedancia de Salida (típico)

PHONES jacks (1, 2): 45 ohms

OUTPUT jacks (1 - 16): 600 ohms

OUTPUT jacks (1 - 8): 600 ohms

Carga de Impedancia Recomendada

PHONES jacks (1, 2): 32 ohms or greater

OUTPUT jacks (1 - 16): 10 k ohms or greater

OUTPUT jacks (1 - 8): 10 k ohms or greater

Carga Mínima de Impedancia

PHONES jacks (1, 2): 16 ohms

Nivel Nominal de Salida (típico)

OUTPUT jacks (1 - 16): +4 dBu (Load impedance: 10 k ohms)

OUTPUT jacks (1 - 8): +4 dBu (Load impedance: 10 k ohms)

Máximo Nivel de Entrada Non Clip (1kHz, típico)

PHONES jacks (1, 2): 500 mW + 500 mW (40 ohms load)

OUTPUT jacks (1 - 16): +22 dBu (10 k ohms load)

OUTPUT jacks (1 - 8): +22 dBu (10 k ohms load)

Nivel de Ruido Residual (IHF-A, tipo * 1)

-89 dBu (All faders: Min)

-82 dBu (Main Fader: Unity, Channel faders: Unity only one CONSOLE INPUT channel, Preamp Gain: Min)

-50 dBu (Main Fader: Unity, Channel faders: Unity only one CONSOLE INPUT channel, Preamp Gain: Max)

* Input 150 ohms terminate

* Output Connector: OUTPUT jacks (M-5000: 1 - 16, M-5000C: 1 - 8)

Nivel de Ruido de
Entrada Equivalente
(EIN) (IHF-A, tipo * 1)

-127 dBu (Main Fader: Unity, Channel faders: Unity only one CONSOLE INPUT channel, Preamp Gain: Max)

* Output Connector: OUTPUT jacks 1 - 16

* Output Connector: OUTPUT jacks 1 - 8

* 1 Frecuencia de Muestreo: 96 kHz

* 2 Conector de Entrada: INPUT Jacks (M-5000: 1 - 16, M-5000C: 1 - 8) (Pad: ON, Ganancia de Entrada: +4dBu, 20 Hz a 40 kHz)

Otras

 M-5000

M-5000C

Pantalla

Graphic color LCD 800 x 600 dots (touch screen)

Graphic organic light emitting display 256 x 64 dots: Fader Bank Display x 7, User Assignable Display x 1

Graphic organic light emitting display 256 x 64 dots: Fader Bank Display x 5, User Assignable Display x 1

Consumo de Energía

180 W

Dimensiones

934 (W) x 725 (D) x 346 (H) mm

36-13/16 (W) x 28-9/16 (D) x 13-5/8 (H) inches

740 (W) x 725 (D) x 346 (H) mm

29-3/16 (W) x 28-9/16 (D) x 13-5/8 (H) inches

Peso

36 kg,  79 lbs 6 oz

32 kg, 70 lbs 9 oz

Temperatura Operacional

+5 to +40 degrees Celsius

+41 to +104 degrees Fahrenheit

Accesorios Incluidos

Owner's manual, Power cord, Dock cable, REAC connector cover x 3, Ferrite core x 6, Cover

Tablet sheet x 2

Tablet sheet x 1

Dimensiones (mm)

M-5000

M-5000C

Diagrama de Bloque de la Mezcladora

M-5000 Mixer Block Diagram

Sección de Monitor

M-5000 Monitor Block Diagram
